Chrysler LHS II (1998-2001) w/0 police package Wiring diagram
This page shows the only wiring diagram for the component.w/0 police package, which is found in the car Chrysler LHS II (1998-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/0 police package (1 of 1)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CIRCUIT BREAKER 1
DK BLU/WHT WIRE
DK GRN (OR RED/WHT) WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DN UP
DOWN
DRIVER POWER WINDOW SWITCH
EXPRESS DOWN MODULE
GRY (OR DK BLU) WIRE
GRY WIRE
GRY/BLK (OR BLU/WHT) WIRE
GRY/BLK WIRE
HOT IN RUN
JUNCTION BLOCK (AT LEFT END OF DASH)
LEFT FRONT
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LOCK OUT SWITCH
LT BLU WIRE
PASSENGER POWER WINDOW SWITCH
RED/BLK WIRE
RIGHT FRONT
RIGHT FRONT POWER WINDOW MOTOR
RIGHT REAR
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
TAN WIRE
VIO WIRE
VIO/WHT WIRE
W/0 POLICE PACKAGE
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> W/0 POLICE PACKAGE
