Chrysler LHS II (1998-2001) pci bus pci bus pci bus Wiring diagram
This page shows the only wiring diagram for the component.pci bus pci bus pci bus, which is found in the car Chrysler LHS II (1998-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pci bus pci bus pci bus (1 of 1)
59 75 65 PCI BUS SCI RECEIVE SCI TRANSMIT
7 43 46 SCI TRANSMIT PCI BUS SCI RECEIVE
AIR BAG CONTROL MODULE (FORWARD OF CENTER CONSOLE)
AUTOMATIC TEMPERATURE CONTROL MODULE (LOWER RIGHT SIDE OF HVAC UNIT HOUSING)
BLK WIRE
BLK/LT GRN WIRE
BODY CONTROL MODULE
CONTROLLER ANTI-LOCK BRAKE (LEFT FENDER SIDE SHIELD)
DATA LINK CONNECTOR (BELOW DASH, LEFT SIDE OF STEERING COLUMN)
FUSE 1
FUSE 19
HOT AT ALL TIMES
HOT IN START, RUN
INSTRUMENT CLUSTER
JUNCTION BLOCK (AT LEFT END OF DASH)
LT GRN WIRE
MEMORY HEATED SEAT/MIRROR MODULE
OVERHEAD TRAVEL INFORMATION SYSTEM
PCI BUS
PCI BUS PCI BUS
PCI BUS PCI BUS PCI BUS
PCI BUS PCI BUS PCI BUS PCI BUS
PNK WIRE
PNK/LT BLU WIRE
PNK/TAN WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
RADIO
RED/WHT WIRE
SENTRY KEY IMMOBILIZER MODULE (IN STEERING COLUMN)
TRANSMISSION CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
VIO/YEL WIRE
YEL/VIO WIRE
Go to component -> Computer data lines -> PCI BUS PCI BUS PCI BUS
