Chrysler LHS II (1998-2001) left front power door lock switch Wiring diagram
This page shows the only wiring diagram for the component.left front power door lock switch, which is found in the car Chrysler LHS II (1998-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front power door lock switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
CIRCUIT BREAKER 2
DK BLU WIRE
DK BLU/WHT WIRE
DOOR AJAR SW SENSE
DOOR LOCK RELAY
DOOR LOCK RELAY CONTROL
DOOR UNLOCK RELAY
DOOR UNLOCK RELAY CONTROL
DRIVER DOOR UNLOCK RELAY
FUSE 14
FUSE 19
HOT AT ALL TIMES
HOT IN START OR RUN
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH) BODY CONTROL MODULE
LEFT FRONT DOOR AJAR SWITCH/ LOCK MOTOR
LEFT FRONT DOOR SW MUX
LEFT FRONT POWER DOOR LOCK SWITCH
LEFT REAR DOOR AJAR SWITCH/ LOCK MOTOR
LEFT UNLOCK RELAY CONTROL
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT FRONT DOOR AJAR SWITCH/ LOCK MOTOR
RIGHT FRONT DOOR SW MUX
RIGHT FRONT POWER DOOR LOCK SWITCH
RIGHT REAR DOOR AJAR SWITCH/ LOCK MOTOR
TAN WIRE
TAN/RED WIRE
TRUNK RELEASE SOLENOID
TRUNK RELEASE SOLENOID/ AJAR SWITCH
TRUNK RELEASE SWITCH
W/ MEMORY SEATS
WHT/DK GRN WIRE
WHT/LT GRN WIRE
Go to component -> Power door lock circuit -> LEFT FRONT POWER DOOR LOCK SWITCH
