Chrysler LHS II (1998-2001) hall effect switches Wiring diagram
This page shows the only wiring diagram for the component.hall effect switches, which is found in the car Chrysler LHS II (1998-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hall effect switches (1 of 1)
AUTOMATIC DAY/NIGHT MIRROR, BACKUP LIGHTS
AUTOSTICK SWITCH
BACK-UP LAMP SWITCH TRANS TEMP SENSOR
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BLU WIRE
DK BLU WIRE
DK BLU/BLK WIRE
ENGINE STARTER MOTOR, FUEL PUMP RELAY IN PDC
FUSE 6 IN JUNCTION BLOCK
FUSE G
FUSE N
FUSE Q
GRN WIRE
HALL EFFECT SWITCHES
HOT AT ALL TIMES
IGNITION SWITCH
JOINT CONNECTOR (IN PDC)
LOCK
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NOL
OFF
ORG/DK BLU WIRE
PNK WIRE
PNK/LT BLU WIRE
POWER DISTRIBUTION CENTER
PRNL
RED WIRE
RED/LT BLU WIRE
RED/WHT WIRE
RUN WIRE
TRANSMISSION RANGE SWITCH (IN TRANSMISSION, ON TOP OF VALVE BODY)
TRANSMISSION RELAY
VIO WIRE
VIO/PNK WIRE
VIO/WHT WIRE
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/DK GRN WIRE
YEL/VIO WIRE
Go to component -> A/t circuit (2 of 3) -> HALL EFFECT SWITCHES
