Chrysler Crossfire I (2003-2007) tps sig 1 sens ground +5 volt tps sig 2 wiring diagram
This page shows the only wiring diagram for the component.tps sig 1 sens ground +5 volt tps sig 2, which is found in the car Chrysler Crossfire I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
tps sig 1 sens ground +5 volt tps sig 2 wiring diagram (1 of 1)
3 6 TRT CTRL MOTOR 1 TRT CTRL MOTOR 2
A/T
ACCEL/SET
ACCEL/SET SIGNAL
ACCELERATOR PEDAL POSITION SENSOR (AT TOP OF ACCELERATOR PEDAL)
APP +5 VOLT
APP SIG (1)
APP SIG (2)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CPP SW SIG
DECEL/SET
DECEL/SET SIGNAL
DK GRN WIRE
DK GRN/BLU WIRE
DK GRN/RED WIRE
FUSE 10
GRY WIRE
HOT IN RUN OR START
KICKDOWN SIG
M/T
NCA WIRE
OFF SIGNAL
OFF SPEED CONTROL SWITCH
ON SIGNAL
ORG/ WIRE
POWERTRAIN CONTROL MODULE (IN CONTROL MODULE BOX)
RED WIRE
RED/BLK WIRE
RESUME
RESUME SIGNAL
SENS GROUND
TPS SIG 1 SENS GROUND +5 VOLT TPS SIG 2
UNDERHOOD ACCESSORY FUSE BLOCK (AT LEFT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
YEL WIRE
YEL/DK GRN WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit -> TPS SIG 1 SENS GROUND +5 VOLT TPS SIG 2
