Chrysler Crossfire I (2003-2007) right door ajar switch Wiring diagram
This page shows the only wiring diagram for the component.right door ajar switch, which is found in the car Chrysler Crossfire I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right door ajar switch (1 of 1)
A/T SHIFT LEVER ASSEMBLY
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
CARGO COMPARTMENT DIVIDER SWITCH
CENTER HIGH MOUNTED STOP LAMP
COUPE
COUPE (LEFT SIDE OF TRUNK, BEHIND TRIM PANEL)
DOME LAMP
DRIVER PASSENGER SEAT SEAT OCCUPANT RESTRAINT CONTROLLER BELT BELT SWITCH SWITCH
FUEL PUMP
LATCH RETAINER SWITCH
LEFT HEATED SEAT CUSHION
LEFT REAR LAMP ASSEMBLY
LEFT REAR SIDE MARKER LAMP
LEFT REAR SIDE MARKER LAMP REAR SPOILER LIMIT SWITCH
LEFT SEAT LEFT HEATED SEAT BACK
LEFT SIDE IMPACT SENSOR
LIFT GATE LOCK SWITCH LICENSE LAMP 2 LICENSE LAMP 1
NCA WIRE
PARK BRAKE SWITCH
PASSENGER SEAT OCCUPANT SIMULATOR
POWER AMPLIFIER
POWER MIRROR SWITCH POWER TOP SWITCH
POWER TOP CONTROL MODULE
POWER TOP HYDRAULIC ASSEMBLY
RADIO
REAR BOW SWITCH
REAR WINDOW DEFOGGER LICENSE LAMP 1
RELAY CONTROL MODULE
RIGHT DOOR AJAR SWITCH
RIGHT HEATED SEAT BACK
RIGHT POWER MIRROR
RIGHT SEAT RIGHT HEATED SEAT CUSHION
RIGHT SIDE IMPACT SENSOR
TONNEAU COVER SWITCH
TRANS- MISSION CONTROL MODULE
TRUNK LATCH ASSEMBLY
WINDOW DEFOGGER
Go to component -> Ground distribution circuit (2 of 2) -> RIGHT DOOR AJAR SWITCH
