Chrysler Crossfire I (2003-2007) rear bow cylinder Wiring diagram
This page shows the only wiring diagram for the component.rear bow cylinder, which is found in the car Chrysler Crossfire I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear bow cylinder (1 of 1)
BASE
BLK WIRE
BLK/DK GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/DK GRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CAN B BUS (-) CAN B BUS (+)
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DK DK
DK GRN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FUSE 5
GRN WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
ORG/ WIRE
POWER AMPLIFIER (BEHIND PASSENGER FOOTWELL)
POWER TOP CONTROL MODULE (AT REAR OF TRUNK)
POWER TOP STATUS SIG
POWER TOPS TRAVEL SENSORS
R ROTATION RLY CTRL L ROTATION RLY CTRL
REAR BOW CYL TRV SENS (BASE) REAR BOW CYL TRV SENS (ROD) SCI TRANSMIT
REAR BOW CYLINDER
RED WIRE
RED/DK GRN WIRE
RED/YEL WIRE
ROD
ROD MAIN CYLINDER
ROTATION RLY GND
SOLENOID
TONNEAU COVER TRAVEL SENSOR
UNDERHOOD ACCESSORY FUSE BLOCK
VIO WIRE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuit (1 of 2) -> REAR BOW CYLINDER
