Chrysler Crossfire I (2003-2007) radio anti-theft tow sensor Wiring diagram
This page shows the only wiring diagram for the component.radio anti-theft tow sensor, which is found in the car Chrysler Crossfire I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio anti-theft tow sensor (1 of 1)
A/C HEATER CONTROL MODULE
BATTERY
BLK WIRE
BLOWER MOTOR
BODY CONTROL MODULE UNIVERSAL GARAGE DOOR OPENER/ TIRE PRESSURE MONITOR
CARGO LAMP DOME LAMP
CENTRAL LOCKING PUMP/ SECURITY SYSTEM MODULE
COOLANT CIRCULATION VALVE COOLANT CIRCULATION PUMP
DATA LINK CONNECTOR
DK GRN WIRE
ENGINE FUSE BLOCK (AT RIGHT REAR OF ENGINE COMPT)
ENGINE STARTER MOTOR
EXCEPT SRT-6
FROM SPLICE BLOCK 102 (DIAGRAM 2 OF 3)
FUSE 14
FUSE 15 FUSE 16
FUSE 2
FUSE 23
FUSE 24 FUSE 19 FUSE 20
FUSE 25 FUSE 26
FUSE 3
FUSE 34 FUSE 36
FUSE 35
FUSE 36
FUSE 4
FUSE 8
FUSE 9
GENERATOR
GRN WIRE
GRY WIRE
HEATED SEAT MODULE BODY CONTROL MODULE
ILLUMINATION CONTROL MODULE
INSTRUMENT CLUSTER
PNK WIRE
POWER AMPLIFIER
POWER MIRROR SWITCH BODY CONTROL MODULE
POWER SEAT RELAY
PULSE MODULE
RADIATOR FAN CONTROL MODULE
RADIO ANTI-THEFT TOW SENSOR
RED WIRE
RELAY CONTROL MODULE (DIAGRAM 2 OF 3)
REMOTE KEYLESS ENTRY RELAY CONSOLE SWITCH GROUP KEY-IN IGNITION SWITCH
SENTRY KEY REMOTE ENTRY MODULE
SIREN
STEERING ANGLE SENSOR
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO UNDERHOOD ACCESSORY FUSE BLOCK FUSE 17 (DIAGRAM 3 OF 3)
TO UNDERHOOD ACCESSORY FUSE BLOCK FUSE 5 (DIAGRAM 3 OF 3)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> RADIO ANTI-THEFT TOW SENSOR
