Chrysler Crossfire I (2003-2007) (occupant restraint controller Wiring diagram
This page shows the only wiring diagram for the component.(occupant restraint controller, which is found in the car Chrysler Crossfire I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (occupant restraint controller (1 of 1)
A/C HEATER CONTROL MODULE POWER TOP CONTROL MODULE POWER TOP HYDRAULIC ASSEMBLY
AIR BAG OFF INDICATOR LAMP
AUTOMATIC DAY/NIGHT MIRROR
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LAMP SWITCH (A/T)
BRN WIRE
CIGAR LIGHTER
COIL ON PLUG 1
COIL ON PLUG 2 COIL ON PLUG 3
COIL ON PLUG 4
COIL ON PLUG 5 COIL ON PLUG 6
CONTROLLER ANTI-LOCK BRAKE
COUPE
DK GRN WIRE
FROM ENGINE FUSE BLOCK FUSE 3 (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM SPLICE BLOCK 100 (DIAGRAM 1 OF 3)
FROM SPLICE BLOCK 101 (DIAGRAM 2 OF 3)
FROM SPLICE BLOCK 102 (DIAGRAM 2 OF 3)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 17
FUSE 18
FUSE 2
FUSE 3
FUSE 31
FUSE 32
FUSE 33 FUSE 5 FUSE 6
FUSE 37
FUSE 5 FUSE 30
FUSE 6
FUSE 7
GLOVE BOX LAMP)
GRN WIRE
HEATED SEAT MODULE
HEATED WASHER NOZZLES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SENTRY KEY REMOTE ENTRY MODULE
LEFT SIDE IMPACT SENSOR
MULTI- FUNCTION SWITCH
NCA WIRE
NOISE SUPPRESSOR 1
NOISE SUPPRESSOR 2
PASSENGER SEAT OCCUPANT SIMULATOR
PNK PNK WIRE
PNK WIRE
PNK/ DK WIRE
PNK/DK GRN WIRE
PNK/RED WIRE
PNK/YEL WIRE
POWER MIRROR SWITCH
RADIO
RECIRCULATED AIR SWITCH- OVER VALVE
RED WIRE
RIGHT SIDE IMPACT SENSOR
SPEED CONTROL SWITCH
UNDERHOOD ACCESSORY FUSE BLOCK (AT LEFT REAR OF ENGINE COMPT)
UNIVERSAL GARAGE DOOR OPENER/ TIRE PRESSURE MONITOR
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> (OCCUPANT RESTRAINT CONTROLLER
