Chrysler Crossfire I (2003-2007) controller antilock brake shift lever assembly Wiring diagram
This page shows the only wiring diagram for the component.controller antilock brake shift lever assembly, which is found in the car Chrysler Crossfire I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram controller antilock brake shift lever assembly (1 of 1)
A/T
AIR PUMP RELAY
BLK WIRE
CONTROLLER ANTILOCK BRAKE SHIFT LEVER ASSEMBLY
DATA LINK CONNECTOR
DK GRN WIRE
ENGINE CONTROL RELAY
FROM SPLICE BLOCK 100 (DIAGRAM 1 OF 3)
FUEL PUMP RELAY
FUSE 1
FUSE 4
FUSE 5
FUSE 6
GRN WIRE
HORN RELAY
IGNITION SWITCH
ILLUMINATION CONTROL MODULE
LOCK OFF
ON LOCK OFF
PNK PNK PNK WIRE
PNK WIRE
PNK/RED WIRE
PNK/YEL WIRE
POWER SEAT RELAY
POWERTRAIN CONTROL MODULE
PULSE MODULE
PULSE MODULE CLUTCH INTERLOCK SWITCH (M/T)
RADIATOR FAN CONTROL MODULE
RED WIRE
RELAY CONTROL MODULE (IN CONTROL MODULE BOX)
SPLICE BLOCK 101 (AT LEFT SIDE OF ENGINE COMPT)
SPLICE BLOCK 102 (AT LEFT SIDE OF ENGINE COMPT)
STEERING ANGLE SENSOR
TO FUSE 33 (DIAGRAM 3 OF 3)
TO FUSE 37 (DIAGRAM 3 OF 3)
TO FUSE 5 (DIAGRAM 3 OF 3)
TO FUSES 1, 2,, 3 (DIAGRAM 3 OF 3)
TO FUSES 10, 11,, 12 (DIAGRAM 3 OF 3)
TO FUSES 30, 31, 32 (DIAGRAM 3 OF 3)
TO FUSES 6, 7 (DIAGRAM 3 OF 3)
TO UNDERHOOD ACCESSORY FUSE BLOCK (DIAGRAM 1 OF 3)
TRACTION SYSTEM RELAY
TRANSMISSION CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> CONTROLLER ANTILOCK BRAKE SHIFT LEVER ASSEMBLY
