Chrysler Crossfire I (2003-2007) 75 18 62 78 31 fuse b+ dome lmp can - can + lg lck sw Wiring diagram

75 18 62 78 31 FUSE B+ DOME LMP CAN - CAN + LG LCK SW 9 8 13 14 16 CAN - CAN + LG LCK SW DR AJAR SW DR AJAR SW BLK/BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (IN CONTROL MODULE BOX) BRN WIRE BRN/GRY WIRE BRN/PNK WIRE BRN/YEL WIRE CARGO LAMP CENTRAL LOCKING PUMP/ SECURITY SYSTEM MODULE (AT RIGHT REAR OF TRUNK) DK GRN WIRE DOME LAMP FUSE 31 FUSE 9 GB SW GLOVE BOX LAMP) GLOVE BOX SWITCH GRY WIRE HOT AT ALL TIMES HOT IN ACC, RUN, START INSTRUMENT CLUSTER, SEATS SYSTEMS LEFT DOOR AJAR SWITCH (REAR OF LEFT DOOR) LIFTGATE LOCK SWITCH (COUPE) POWER DISTRIBUTION SYSTEM RED WIRE RED/GRY WIRE RIGHT DOOR AJAR SWITCH (REAR OF RIGHT DOOR) UNDERHOOD ACCESSORY FUSE BLOCK (AT LEFT REAR OF ENGINE COMPT) WHT WIRE
