Chrysler Crossfire I (2003-2007) 2 3 fused ign switch out lt side impact sig ground Wiring diagram

1 2 3 IGN SW OUT PASS AIR BAG OFF GND 1 2 3 ON/OFF SENS (ON) 2 1 DRVR SB SQUIB LINE 1 DRVR SB SQUIB LINE 2 2 1 PASS SB SQUIB LINE 1 PASS SB SQUIB LINE 2 2 3 FUSED IGN SWITCH OUT LT SIDE IMPACT SIG GROUND 2 3 FUSED IGN SWITCH OUT RT SIDE IMPACT SIG GROUND AIR BAG OFF INDICATOR LAMP AIR BAG WARNING INDICATOR BLK WIRE BLU WIRE BLU/BLK WIRE BLU/DK GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/DK GRN WIRE BRN/YEL WIRE CLOCK SPRING (BEHIND STEERING WHEEL) DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DK GRN WIRE DK GRN/BLK WIRE DRIVER SEAT BELT SWITCH (IN DRIVER SIDE SEAT BELT BUCKLE) DRIVER SEAT BELT TENSIONER SQUIB (IN DRIVER SEAT BELT TENSIONER) DRVR AB OFF IND DRVR SQUIB LINE 1 12 13 DRVR SB TEN SW SENS PASS SQUIB LINE 2 EAR DRIVER FUSE 2 FUSE 3 GRN WIRE GROUND GRY WIRE GRY/BLU WIRE GRY/DK GRN WIRE HOT IN ACC, ON OR START INSTRUMENT CLUSTER LEFT SIDE AIR BAG SQUIB (REAR OF LEFT DOOR) LEFT SIDE IMPACT SENSOR (ON FLOOR, UNDER DRIVER'S SEAT) LEFT SQUIB LINE 1 LEFT SQUIB LINE 2 LEFT SQUIB LINE 1 LEFT SQUIB LINE 2 PASS SQUIB LINE 2 NCA WIRE OCCUPANT RESTRAINT CONTROLLER (UNDER CENTER CONSOLE) ON/OFF SENS (OFF) PASS SQUIB LINE 1 PASS SQUIB LINE 1 PASS AB ON/OFF SIG LT SQUIB LINE 2 LT SQUIB LINE 1 15 16 PASSENGER AIR BAG ON/OFF SWITCH PASSENGER AIR BAG SQUIB (BEHIND RIGHT SIDE OF DASH) DRIVER FRONT AIR BAG SQUIB PASSENGER SEAT BELT SWITCH (IN PASSENGER SEAT BELT TENSIONER) PASSENGER SEAT BELT TENSIONER SQUIB (IN PASSENGER SEAT BELT TENSIONER) PASSENGER SEAT OCCUPANT SIMULATOR (BEHIND PASSENGER FOOTWELL) PNK WIRE PNK/YEL WIRE PNK/YEL/DK GRN WIRE POWERTRAIN CONTROL MODULE (IN CONTROL MODULE BOX) RED WIRE RIGHT SIDE AIR BAG SQUIB (REAR OF RIGHT DOOR) RIGHT SIDE IMPACT SENSOR (ON FLOOR, UNDER RIGHT SEAT) RIGHT SIDE SQUIB LINE 1 RIGHT SIDE SQUIB LINE 2 RT SQUIB LINE 1 UNDERHOOD ACCESSORY FUSE BLOCK (AT LEFT REAR OF ENGINE COMPT) VIO WIRE WARNING SYSTEM WHT WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE
