Chrysler 300M I (1998-2004) 1 2 3 4 5 6 ign run/start pci bus line 1 line 2 Wiring diagram

1 2 3 4 5 6 IGN RUN/START PCI BUS LINE 1 LINE 2 1 2 3 4 5 6 IGN RUN/START PCI BUS LINE 1 LINE 2 GROUND GROUND AIR BAG WARNING INDICATOR AIRBAG CONTROL MODULE (ORC) (ON TUNNEL FLOOR PAN, FORWARD OF CENTER CONSOLE) BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/YEL WIRE BODY CONTROL MODULE (AT LEFT END OF DASH, ATTACHED TO JUNCTION BLOCK) CLOCK- SPRING DATA LINK CONNECTOR (DLC) (PARTIAL) (BELOW DASH, TO LEFT OF STEERING COLUMN) DK BLU WIRE DK BLU/YEL WIRE DK GRN WIRE DK GRN/LT BLU WIRE DK GRN/YEL WIRE DODGE DRIVER AIRBAG LINE 2 EARLY PRODUCTION LATE PRODUCTION FUSE 1 FUSE 22 FUSE 8 GROUND HOT IN HOT IN OFF, RUN OR START HOT IN RUN OR START IGN RUN/START IGN RUN GROUND INSTRUMENT CLUSTER JUNCTION BLOCK (AT LEFT END OF DASH) LEFT SEAT AIRBAG LEFT SIDE IMPACT AIRBAG CONTROL MODULE (ORC) LINE 1 LINE 2 LINE 1- LINE 2- LT BLU WIRE LT BLU/ORG WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/ORG WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE NCA WIRE OTHER PASSENGER AIRBAG PCI BUS POWERTRAIN CONTROL MODULE (PCM) (IN LEFT REAR OF ENGINE COMPARTMENT) RED WIRE RIGHT SEAT AIRBAG RIGHT SIDE IMPACT AIRBAG CONTROL MODULE (ORC) RUN WIRE VIO WIRE VIO/YEL WIRE WHT WIRE YEL WIRE
