Heated seats circuit, w/ ventilation for Chrysler 200 II (2014-2016)

BLK WIRE BRN/LT GRN WIRE CAN IHS (-) COMFORT SEAT STEERING WHEEL MODULE COMPUTER DATA LINES SYSTEM DK BLU/LT GRN WIRE FSD IGN FSD IGN SW OUTPUT FUSED IGN GRY/LT BLU WIRE HEATED STEERING WHEEL CIRCUIT HEATER CTRL HTD SEAT SENS RTN HTD STR WHL FEED HTD STR WHL RTN LEFT SEAT BACK HEATER LEFT SEAT BACK VENT MOTOR LEFT SEAT CUSHION HEATER LEFT SEAT CUSHION VENT MOTOR LF HEATER LF HTD SEAT TEMP SENSE LF SEAT LF SEAT HEATER CTRL LH SEAT VENT RTN LT GRN/BRN WIRE LT GRN/VIO WIRE ORG/LT GRN WIRE PNK/YEL WIRE RF HTD SEAT TEMP SENSE RF SEAT HEATER CTRL RH SEAT VENT RTN SEAT TEMP SENS TAN/DK BLU WIRE TAN/WHT WIRE TAN/YEL WIRE WHT WIRE WHT/DK BLU WIRE

BLK WIRE BRN/LT GRN WIRE FSD IGN FUSE 63 FUSE 64 HEATER CTRL HOT W/ RUN RELAY 1 ENERGIZED HTD SEAT SENS RTN LT GRN/VIO WIRE PNK/YEL WIRE POWER DISTRIBUTION CENTER ASSEMBLY RF HTD RF SEAT RH SEAT VENT RTN RIGHT SEAT BACK HEATER RIGHT SEAT BACK VENT MOTOR RIGHT SEAT CUSHION HEATER RIGHT SEAT CUSHION VENT MOTOR SEAT TEMP SENSE TAN/DK BLU WIRE TAN/WHT WIRE
