Chrysler 200 II (2014-2016) panel lmps drv Wiring diagram
This page shows the only wiring diagram for the component.panel lmps drv, which is found in the car Chrysler 200 II (2014-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panel lmps drv (1 of 1)
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
CAN C (+)
CAN IHS (-)
CENTER CONSOLE
CIRCUIT BOARD
CLUSTER
COMPUTER DATA LINES SYSTEM
CONSOLE CIGAR LIGHTER
DECKLID RELEASE SWITCH
ELECTRONIC OVERHEAD MODULE
FSD B(+)
FUSE 23
HDLP SW MUX
HDLP SW MUX RTN
HEADLAMP SWITCH
HOT AT ALL TIMES
MEDIA PORT
ORG/BRN WIRE
ORG/GRY WIRE
ORG/LT GRN WIRE
ORG/TAN WIRE
ORG/YEL WIRE
PANEL LMPS DIM SW MUX
PANEL LMPS DRV
PARKING BRAKE SWITCH
PASS WNDW SW ILL
PASS WNDW SW RTN
PASSENGER DOOR MODULE
PASSENGER WINDOW/DOOR LOCK SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY
POWER DISTRIBUTION SYSTEM
PREMIUM
PRK BRK SW SNS
RED WIRE
RED/GRY WIRE
VOLTAGE STABILITY MODULE
W/ START/STOP W/O START/STOP PREMIUM BASE
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> PANEL LMPS DRV
