Chrysler 200 II (2014-2016) cigar lighter console Wiring diagram
This page shows the only wiring diagram for the component.cigar lighter console, which is found in the car Chrysler 200 II (2014-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cigar lighter console (1 of 1)
AUTO SHUT DOWN RELAY
BASE
BLK WIRE
BODY CONTROL MODULE
CENTER CONSOLE
CIGAR LIGHTER CONSOLE
DRIVER WINDOW/ DOOR LOCK SWITCH
FROM RUN RELAY 2 (DIAGRAM 1 OF 8)
FROM RUN/ ACCESSORY RELAY 2 (DIAGRAM 2 OF 8)
FROM STARTER SOLENOID RELAY 2 (DIAGRAM 3 OF 8)
FSD B(+)
FSD IGN SW
FUEL PUMP RELAY
FUSE 22
FUSE 25
FUSE 60
FUSE 75
FUSE 95
HORN RELAY
INSIDE REAR VIEW MIRROR
LEFT HID HEADLAMPS RELAY
LT GRN/LT BLU WIRE
ORG/GRY WIRE
OUTPUT
PANEL LPS
PASSENGER WINDOW/ DOOR LOCK SWITCH
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER OUTLET CONSOLE
POWER WINDOW CIRCUIT BREAKER 3
PREMIUM
RADIATOR FAN RELAY
RAIN LIGHT SENSOR MODULE
RED WIRE
RIGHT LOW BEAM HEADLAMP RELAY
RUN/ ACCESSORY RELAY 1
RUN/ ACCESSORY RELAY 2
SUNROOF MODULE
SUNROOF MOTOR
SUNROOF SHADE MOTOR
TO FUSE 19 (DIAGRAM 3 OF 8)
TO FUSE 25 (DIAGRAM 2 OF 8)
W/ DUAL PANEL
W/ SINGLE PANEL
W/ START/ STOP
W/ SUNROOF
W/O SUNROOF
WASHER PUMP RELAY
Go to component: -> Power distribution circuit (2 of 8) -> CIGAR LIGHTER CONSOLE
