Chrysler 200 I (2010-2014) transmission trans range sensor rng park/ neu sig Wiring diagram
This page shows the only wiring diagram for the component.transmission trans range sensor rng park/ neu sig, which is found in the car Chrysler 200 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission trans range sensor rng park/ neu sig (1 of 1)
1 2 GND IGNITION SW SENS
1 7 6 IGNITION SW SENS CAN BUS (-) CAN BUS (+)
2.4L 3.6L
6 SPEED A/T
B(+)
BATTERY
BATTERY REMOTE
BATTERY REMOTE POSITIVE POST (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BUS BAR
CAN CAN BUS (-) BUS (+)
CAN-BUS
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/ORG WIRE
FUSIBLE LINK 1
GENERATOR
GRY WIRE
HOLD-IN
IGNITION SWITCH
LT BLU WIRE
NCA WIRE
NEGATIVE POST (LEFT SIDE OF ENGINE COMPT)
ORG/ WIRE
POWER DISTRIBUTION
POWERTRAIN CONTROL MODULE (3.6L) (LEFT REAR OF ENGINE COMPT)
PULL- IN
RED WIRE
STARTER
STARTER COIL MTR FD
STRTR OVRDE RLY COIL RTN
SYSTEM
TOTALLY INTEGRATED POWER MODULE
TRANSMISSION TRANS RANGE SENSOR RNG PARK/ NEU SIG
VIO/BRN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/LT BLU WIRE
WHT/ORG WIRE
WIRELESS IGNITION NODE (STEERING COLUMN)
YEL WIRE
YEL/DK BLU WIRE
Go to component -> Starting circuit -> TRANSMISSION TRANS RANGE SENSOR RNG PARK/ NEU SIG
