Chrysler 200 I (2010-2014) snsr sig cam postn Wiring diagrams

This page contains all the electrical diagrams for the component. snsr sig cam postn, in which he is found in the car Chrysler 200 I (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram snsr sig cam postn (1 of 2)

Wiring diagram snsr sig cam postn for Chrysler 200 I (2010-2014) (1 of 2)

Get access

AIR CONDITIONING SYSTEM BLK/ORG WIRE BRN/DK BLU WIRE BRN/DK GRN WIRE BRN/LT BLU WIRE BRN/ORG WIRE BRN/TAN WIRE BRN/WHT WIRE BRN/YEL WIRE CAM POSTN SNSR SIG CMPRSR CTRL COIL ON PLG DRV 4 CRK SPD SNSR OUTPUT CRKSHFT POSTN SNSR RTN CSHFT POSTN SNSR SIG 2 DK BLU/BRN WIRE DK BLU/DK GRN WIRE DK BLU/GRY WIRE DK BLU/LT BLU WIRE DK BLU/ORG WIRE DK BLU/TAN WIRE ENG CTRL COM SNSR RTN IGNITION CAPACITOR LT BLU/WHT WIRE MASS AIR FLW SNSE RTN OIL PRESS SNSE/SW SIG OIL PRESS SW BREATHER OIL PRESSURE SWITCH (LOWER LEFT SIDE OF ENGINE) PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE RED WIRE SEC FD SNSE/SW SIG OIL PRESS SNSR SIG CAM POSTN THRTL POS SNSR RTN THRTL POS SNSR SIG 1 THRTL POS SNSR SIG 2 VIO/DK BLU WIRE VIO/GRY WIRE YEL/PNK WIRE

Go to component -> Wiring diagram engine performance 2.4l, 4 speed a/t (4 of 6) -> SNSR SIG CAM POSTN

Wiring diagram snsr sig cam postn (2 of 2)

Wiring diagram snsr sig cam postn for Chrysler 200 I (2010-2014) (2 of 2)

Get access

Go to component -> Wiring diagram engine performance 2.4l, 6 speed a/t (4 of 6) -> SNSR SIG CAM POSTN
