Chrysler 200 I (2010-2014) radiator fan series/ parallel relay Wiring diagram
This page shows the only wiring diagram for the component.radiator fan series/ parallel relay, which is found in the car Chrysler 200 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radiator fan series/ parallel relay (1 of 1)
2.4L DOHC
ASD/ MAIN RELAY
AUTOMATIC A/C
BATTERY
BATTERY REMOTE POSITIVE POST (LEFT SIDE OF ENGINE COMPT)
BRN WIRE
BUS BAR
DATA LINK CONNECTOR
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT SWITCH
EXCEPT 2.4L DOHC
FUSE
FUSE 15
FUSE 19
FUSE 2
FUSE 3
FUSIBLE LINK 1
GENERATOR
GRY WIRE
HANDS FREE MODULE (IF EQUIPPED)
IN HEADLAMP, DASH HARNESS)
LEFT ANALOG MULTI-FUNCTION CLOCK SWITCH MODULE
LOWER BANK SWITCH
MANUAL A/C
MIRROR A/C HEATER SWITCH CONTROL
NCA WIRE
PASSENGER SEAT SWITCH (CONVERTIBLE)
PNK WIRE
POWER DISTRIBUTION CENTER
POWER MODULE (LEFT SIDE OF ENGINE COMPT)
POWER TOP MODULE (CONVERTIBLE)
POWERTRAIN CONTROL MODULE
RADIATOR FAN SERIES/ PARALLEL RELAY
RADIATOR FAN- LOW/ HIGH RELAY
RADIATOR FAN- MEDIUM/ HIGH RELAY
RADIO, AMPLIFIER
REAR POWER DISTRIBUTION CENTER (W/ DUAL CLUTCH TRANSMISSION)
RED WIRE
SECONDARY REAR POWER AIR PUMP DISTRIBUTION CENTER (2.4L PZEV) (3.6L)
SEDAN
STARTER
STOP LAMP SWITCH
TOTALLY INTEGRATED
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
VIO WIRE
W/ HANDS FREE
WIRELESS IGNITION NODE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> RADIATOR FAN SERIES/ PARALLEL RELAY
