Chrysler 200 I (2010-2014) pwr top snse sig Wiring diagram
This page shows the only wiring diagram for the component.pwr top snse sig, which is found in the car Chrysler 200 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr top snse sig (1 of 1)
BATT FEED MTR ROOF HDR LTCH SIG WDO DWN RR LT GND WDO UP RR LT
BLK WIRE
DCK LTCH SIG TO MOD
DECKLID LATCHED LIMIT SWITCH (LEFT SIDE OF TRUNK)
DIM 3 IP
FUSE 24
FUSE 37
HEADER LATCH MOTOR (CENTER OF HEADER)
HOT AT ALL TIMES
LT GRN/BLK WIRE
LT GRN/BRN WIRE
LT GRN/VIO WIRE
MTR ROOF HDR LTCH SIG
MTR ROOF HDR UNLTCH SIG
MTR TONU EXTND SIG
MTR TONU RETRAC SIG
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/DK BLU WIRE
ORG/GRY WIRE
ORG/LT GRN WIRE
ORG/PNK WIRE
ORG/VIO WIRE
PANEL LATCHED LIMIT SWITCH
POWER TOP MODULE (LEFT REAR QUARTERPANEL)
POWER TOP SWITCH
POWER WINDOWS SYSTEM
PWR TOP SNSE SIG
PWR TOP SW RTN
RED WIRE
RED/WHT WIRE
ROOF PNL LTCH SIG
ROOF SENSE LIMIT SWITCH (RIGHT SIDE OF HEADER)
ROOF SNSE SIG
TAN/LT BLU WIRE
TAN/YEL WIRE
TONNEAU COVER MOTOR (CENTER REAR OF TRUNK LID)
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
Go to component -> Power top/sunroof circuit, convertible (2 of 2) -> PWR TOP SNSE SIG
