Chrysler 200 I (2010-2014) prim snsr fd 1 Wiring diagram

BLK WIRE BRN WIRE BRN/DK BLU WIRE BRN/DK GRN WIRE BRN/LT BLU WIRE BRN/ORG WIRE BRN/TAN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR 2 (REAR OF LEFT CYLINDER BANK) COOL TEMP CRANKSHAFT POSITION SENSOR (RIGHT REAR OF ENGINE) CRK SPD CRKSHFT POSTN CSHFT POS DK BLU/DK GRN WIRE DK BLU/GRY WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK BLU/TAN WIRE DK BLU/YEL WIRE ENG CTRL COM ENGINE COOLANT TEMPERATURE SENSOR (TOP LEFT REAR OF ENGINE) HTR FD INTAKE VARIABLE VALVE TIMING SOLENOID (FRONT OF LEFT CYLINDER BANK) INTKE VVT SOL DRV 2 MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (TOP RIGHT SIDE OF ENGINE) MAP SNSR SIG NEG CTRL OIL PRESS OIL PRESSURE SENSOR (RIGHT REAR OF ENGINE) OXYGEN SENSOR 1/2 (RIGHT SIDE OF ENGINE, IN EXHAUST) PNK/YEL WIRE POS CTRL PRIM FD PRIM SNSR FD 1 SEC FD SNSE RTN SNSE/SW SIG SNSR OUTPUT SNSR RTN SNSR SIG SNSR SIG (1) SNSR SIG 2 SNSR SIG 3 SNSR SIG 4 THROTTLE BODY (TOP RIGHT SIDE OF ENGINE) THRTL POS THRTL POS MTR VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE YEL/PNK WIRE
