Chrysler 200 I (2010-2014) 3 2 1 lgate pwr rel lgate ajar sig gnd Wiring diagram
This page shows the only wiring diagram for the component.3 2 1 lgate pwr rel lgate ajar sig gnd, which is found in the car Chrysler 200 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 2 1 lgate pwr rel lgate ajar sig gnd (1 of 1)
10 16 32 28 23 GND CAN BUS(-) CAN BUS(+) DECK POS RTN DECK POS SIG
2 1 RTN SIG
3 2 1 LGATE PWR REL LGATE AJAR SIG GND
BATT FD
BLK WIRE
CARGO LAMP
CLUSTER
COMPUTER DATA LINES SYSTEM
DECKLID DOOR LATCH
DECKLID POSITION SENSOR (LEFT SIDE OF TRUNK)
DECKLID RELEASE SWITCH DECKLID/ LGATE REL SW SIG
DECKLID/ LGATE REL SW
FUSE 10
FUSE 37
HOT AT ALL TIMES
HOT AT ALL TIMES TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
LGATE AJAR SIG
LGATE PWR REL
LT GRN WIRE
NCA WIRE
ORG/LT GRN WIRE
ORG/YEL WIRE
POWER TOP MODULE (CONVERTIBLE) (LEFT REAR QUARTERPANEL)
RED WIRE
RED/WHT WIRE
SIG
TAN/YEL WIRE
VIO/ORG WIRE
WHT WIRE
WHT/ORG WIRE
Go to component -> Deck lid release circuit -> 3 2 1 LGATE PWR REL LGATE AJAR SIG GND
