Chrysler 200 I (2010-2014) 22 23 1 trans rng temp snsr sig snsr rtn com snsr rtn Wiring diagram
This page shows the only wiring diagram for the component.22 23 1 trans rng temp snsr sig snsr rtn com snsr rtn, which is found in the car Chrysler 200 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 22 23 1 trans rng temp snsr sig snsr rtn com snsr rtn (1 of 1)
2-4 PRESS SOL SW SIG
2-4/LR SOL CTRL
22 23 1 TRANS RNG TEMP SNSR SIG SNSR RTN COM SNSR RTN
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/DK BLU WIRE
DK GRN/GRY WIRE
DK GRN/LT BLU WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
DR PRESS SW
DR SOL CTRL
EMC SOL CTRL
LC PRESS SW
LC SOL CTRL
LNE PRESS TRANS SIG
LO RVSE PRESS SOL SW SIG
LR/CC SOL CTRL
OD SOL CTRL
OVRDRV PRESS SW SIG
SWD BATT FD
TRANS RNG PRK/NEUT SIG
TRANSMISSION SOLENOID/ PRESSURE SWITCH ASSEMBLY (3.6L: LEFT SIDE OF TRANSAXLE)
UD SOL CTRL
VAR FRCE SOL FD/SGNL
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/TAN WIRE
Go to component -> Transmission circuit, 6 speed without dual clutch (2 of 2) -> 22 23 1 TRANS RNG TEMP SNSR SIG SNSR RTN COM SNSR RTN
