Chrysler 200 I (2010-2014) 1 2 3 bstr vac press sig bstr vac snsr rtn bstr vac snsr fd Wiring diagram

1 2 3 4 CAN BUS (+) CAN BUS (-) GND IGN SW OUT (RUN-START) 1 2 3 BSTR VAC PRESS SIG BSTR VAC SNSR RTN BSTR VAC SNSR FD 12 11 CAN BUS (+) CAN BUS (-) 6 7 8 FUSED B(+) GROUND LIN CCN ABS/ESP SNSR CLSTR FD ABS/ESP SNSR CLSTR RTN ANTI-LOCK BRAKE MODULE (LOWER RIGHT REAR OF ENGINE COMPT) B(+) BATT FD BLK WIRE BRAKE FLUID FUSE 28 LEVEL SIGNAL BRAKE FLUID LEVEL SENSOR (3.6L: BRAKE FLUID RESERVOIR) BRK FLUD LVL SW BSTR VAC PRESS SIG RR WHL (-) RR WHL (+) BSTR VAC SNSR FD BSTR VAC SNSR RTN CAN BUS (+) YAW CAN BUS (-) YAW CAN CAN BUS (-) BUS (+) CAN-BUS CAN-BUS CIRCUIT BOARD CLUSTER COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/GRY WIRE DK GRN/LT BLU WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DK GRN/TAN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DYNAMICS SENSOR (FRONT OF CENTER CONSOLE) FUSE 3 FUSE 34 FUSE 35 FUSED B (+) FUSED B(+) RF WHL (-) RF WHL (+) GRN WIRE GROUND HOT AT ALL TIMES HOT IN ON OR START IGN SW OUT (RUN-START) LEFT FRONT ABS WHEEL SPEED SENSOR (ON LEFT FRONT WHEEL HUBS) LF WHL (+) LF WHL (-) GROUND LIN CCN LOWER BANK SWITCH LR WHL (+) LR WHL (-) LT BLU WIRE NCA WIRE ORG/ WIRE PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER) PNK WIRE PNK/ DK WIRE PNK/WHT WIRE PRK BRK SW SIG RED WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUBS) STEERING CONTROL MODULE (STEERING COLUMN) STOP LAMP SW OUT STOP LAMP SWITCH (TOP OF BRAKE PEDAL) STP LMP FD VACUUM PRESSURE SENSOR (CENTER REAR OF ENGINE COMPT) VIO/DK BLU WIRE VIO/LT BLU WIRE WHT WIRE WHT/BLK WIRE WHT/DK BLU WIRE WHT/DK GRN WIRE WHT/LT BLU WIRE WHT/ORG WIRE WHT/YEL WIRE
