Chevrolet Volt II (2015-2019) key capture/column lock shift pos sig Wiring diagram

AUTOMATIC TRANSMISSION ASSEMBLY BATTERY POSITIVE VOLT BCM 2 FUSE BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE (PASSENGER CENTER CONSOLE) BRAKE PEDAL POSITION SENSOR BRK APPLY SENS CTRL BRK APPLY SENS LOW REF BRK APPLY SENS SIG BRK POS SENS LOW REF BRK POS SENS SIG BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (BELOW LEFT HEADLAMP) GRN WIRE GRY WIRE HI SPD GMLAN SERIAL DATA (-) (1) HI SPEED GMLAN SERIAL DATA (-) 1 HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK INTERNAL MODE SW VOLT SPLY A INTERNAL MODE SW VOLT SPLY B KEY CAPTURE/COLUMN LOCK SHIFT POS SIG ORG/ WIRE PARK LOCK SOL CTRL PARK POSITION SWITCH PNK WIRE POWER INVERTER MODULE (TOP OF TRANSMISSION) RED/BLU WIRE TRANS IMS MODE SW S BIT SIG TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION SHIFT LEVER TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR VIO/BLK WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLK WIRE
