Chevrolet Volt II (2015-2019) a/c low side pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.a/c low side pressure sensor, which is found in the car Chevrolet Volt II (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c low side pressure sensor (1 of 1)
A/C LOW SIDE PRESSURE SENSOR
AMBIENT AIR TEMPERATURE SENSOR
BATT 4 (+)
BATT POS
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BUS 19
COMPUTER DATA LINES SYSTEM
COOLANT HEATER CONTROL MODULE (NEAR ENGINE CRANKSHAFT PULLEY)
DATA 1 (+)
FUSE 1
FUSE 3
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HI VOLT (-)
HOT AT ALL TIMES
HYBRID/EV BATTERY CONTACTOR ASSEMBLY
HYBRID/EV BATTERY COOLANT LEVEL SWITCH
HYBRID/EV BATTERY PACK
HYBRID/EV BATTERY PACK FUSE HOLDER 1
ORG/ WIRE
ORG/BLK WIRE
PASSENGER COMPARTMENT HEATER COOLANT CONTROL VALVE
RED/GRY WIRE
SER DATA
VIO/BRN WIRE
VOLT
W/ PARK ASSIST W/O PARK ASSIST
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Automatic a/c circuit (3 of 6) -> A/C LOW SIDE PRESSURE SENSOR
