Power mirrors circuit for Chevrolet Volt I (2010-2015)
Power mirrors circuit
BLK WIRE
BLK/BRN WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DEFOGGER SYSTEM
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DOWN
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
DRIVER OUTSIDE REARVIEW MIRROR MOTOR
DRVR DR SW FUSE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT
LEFT TURN SIGNAL REPEATER LAMP
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/VIO WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR GLASS RIGHT TURN
PASSENGER OUTSIDE REARVIEW MIRROR MOTOR
REAR BODY FUSE BLOCK (LEFT REAR CORNER OF LUGGAGE COMPT)
RED/WHT WIRE
RIGHT
SIGNAL REPEATER LAMP
WHT WIRE
YEL WIRE
YEL/LT GRN WIRE
YEL/WHT WIRE
