Chevrolet Volt I (2010-2015) tp sens 1 sig low ref tp sens 2 sig tac ctrl close tac ctrl open Wiring diagram

12 VOLT REF 19 24 25 LOW REF DATA BUS - DATA BUS + 33 52 38 10 24 30 2 16 29 43 CRUISE/ETC/TCC BRK SIG CHECK ENGINE IND CTRL 7 13 SENSOR SIG SENSOR SPLY VOLT ACCELERATOR PEDAL POSITION SENSOR (PART OF ACCELERATOR PEDAL ASSEMBLY) BLK WIRE BLK/BRN WIRE BLK/LT BLU WIRE BLK/VIO WIRE BODY CONTROL MODULE (UNDER RIGHT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRN/DK GRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/RED WIRE BRN/WHT WIRE CANCEL CRUISE SWITCH COMPUTER DATA LINES SYSTEM CRUISE CTRL CRUISE IND CRUISE/ETC/TCC BR SIG DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROL MODULE (LEFT FRONT CORNER OF ENGINE COMPT) GROUND INSTRUMENT PANEL CLUSTER LEFT STEERING WHEEL CONTROL SWITCH LOGIC LOW REF ACC PEDAL POSITION SIG 1 LOW REF ACC PEDAL POSITION SIG 2 LT BLU WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/WHT WIRE MAIN RLY FUSED SPLY (1) RED WIRE RES+ SER DATA SERIAL DATA BUS (+) SERIAL DATA BUS (-) SET- SOUND SYSTEMS STEERING WHEEL AIR BAG COIL (TOP OF STEERING COLUMN) THROTTLE BODY (ON INTAKE MANIFOLD ASSEMBLY) TP SENS 1 SIG LOW REF TP SENS 2 SIG TAC CTRL CLOSE TAC CTRL OPEN TRANSMISSION OUTPUT SHAFT SPEED SENSOR VIO WIRE VIO/LT BLU WIRE WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
