Chevrolet Volt I (2010-2015) telematics communications interface control module Wiring diagrams
This page contains all the electrical diagrams for the component. telematics communications interface control module, in which he is found in the car Chevrolet Volt I (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram telematics communications interface control module (1 of 2)
AMP FUSE
AMPLIFIER CONTROL
AUDIO AMPLIFIER
B+ VOLT
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BRN/LT BLU WIRE
BRN/LT GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CELLULAR TELEPHONE VOICE SIG
COAX
COMPUTER DATA LINES SYSTEM
DRAIN WIRE
GROUND
GRY/YEL WIRE
HOT AT ALL TIMES REAR BODY FUSE BLOCK (LEFT REAR CORNER CORNER OF LUGGAGE COMPT)
L/R SUBWOOFER (-)
LEFT FRONT TWEETER SPEAKER
LF LOW LEVEL AUDIO (-)
LF LOW LEVEL AUDIO SIG
LF SPKR
LF SPKR SIG (-) (1)
LOW GMLAN SERIAL DATA
LOW REFERENCE
LR LOW LEVEL AUDIO (-)
LR LOW LEVEL AUDIO SIG +
LR SPKR
LR SPKR SIG (-)
LT BLU LT BLU/BRN WIRE
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/BRN WIRE
LT BLU/GRY WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
NCA WIRE
RED/BRN WIRE
REMOTE ENABLE SIG
RF LOW LEVEL AUDIO SIG
RF LOW LVL AUD(-)
RF SPKR
RF SPKR SIG (-)
RF TWEETER SPKR (-)
RR LOW LEVEL AUDIO (-)
RR LOW LEVEL AUDIO SIG +
RR SPKR
RR SPKR SIG (-)
SUBWOOFER SPEAKER
TELEMATICS COMMUNICATIONS INTERFACE CONTROL MODULE
VIO/BRN WIRE
VIO/LT BLU WIRE
VOICE RECOGNITION AUDIO SIG
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
Go to component -> Navigation circuit, with amplifier (2 of 3) -> TELEMATICS COMMUNICATIONS INTERFACE CONTROL MODULE
