Chevrolet Volt I (2010-2015) multi-axis acceleration sensor (under center Wiring diagram
This page shows the only wiring diagram for the component.multi-axis acceleration sensor (under center, which is found in the car Chevrolet Volt I (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi-axis acceleration sensor (under center (1 of 1)
1 3 HI SPD GMLAN SERIAL DATA - HI SPD GMLAN SERIAL DATA +
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BODY CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
BRAKE CONTROL BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRAKE FLUID LEVEL SWITCH (MASTER CYLINDER ASSEMBLY)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRK APPLY SENS SIG
BRK APPLY SENS SPLY VOLT
BRK PDL TRAVEL SENS 1 HI REF
BRK PDL TRAVEL SENS 1 SIG
BRK PDL TRAVEL SENS 2 SIG
BRN WIRE
BRN/WHT WIRE
COMBINED VEHICLE INERTIAL SENS SPLY VOLT
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONSOLE)
CRUISE/ETS/TCC BRAKE SIG
DATA
ENGINE CONTROL MODULE (LEFT FRONT CORNER OF ENGINE COMPT)
GRY/BLK WIRE
HI SPD GMLAN SERIAL DATA
LO REF
LO SPD GMLAN SERIAL DATA
LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/RED WIRE
LT BLU/VIO WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/BRN WIRE
LT GRN/GRY WIRE
MULTI-AXIS ACCELERATION SENSOR (UNDER CENTER
OVERHEAD CONSOLE MULTIFUNCTION SWITCH
PARK BRAKE CONTROL SWITCH
STEERING ANGLE SENSOR (TOP OF STEERING COLUMN, BEHIND STEERING WHEEL)
SYSTEM
TRACTION CONTROL SWITCH
TRACTION CTRL SWITCH SIG
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/BRN WIRE
WHT WIRE
WHT/LT BLU WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> MULTI-AXIS ACCELERATION SENSOR (UNDER CENTER
