Chevrolet Volt I (2010-2015) mtr enable Wiring diagrams
This page contains all the electrical diagrams for the component. mtr enable, in which he is found in the car Chevrolet Volt I (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mtr enable (1 of 2)
B+ VOLT
BLK WIRE
BLK/YEL WIRE
BRN/LT BLU WIRE
BRN/LT GRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN
FAN CTRL
FAN ENABLE
FAN FEED- BACK SIG
FUSE
HOT AT ALL TIMES APM FAN FUSE
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
HYBRID/EV POWERTRAIN CONTROL MODULE 2 (UNDER FRONT PASSENGER'S SEAT)
LOW REF
LOW SPD SERIAL DATA
LT GRN WIRE
LT GRN/VIO WIRE
MTR CTRL
MTR ENABLE
MTR FEED- BACK SIG
REAR BODY FUSE BLOCK (LEFT REAR CORNER OF LUGGAGE COMPT)
RED/BRN WIRE
RED/LT BLU WIRE
SENS SIG
VIO/LT BLU WIRE
YEL/GRY WIRE
YEL/LT GRN WIRE
Go to component -> Hybrid cooling fan circuit -> MTR ENABLE
Wiring diagram mtr enable (2 of 2)
3788 3787 3791 COOLING FANS SYSTEM COMPUTER DATA LINES SYSTEM
3790 3953 COOLING FANS SYSTEM
3827 3954 2364 5139 3793 TRUNK, TAILGATE, FUEL DOORS SYSTEM
59 60 61 HIGH CONTROL
62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 PILOT SIG IND CTRL
6801 3794 TRUNK, TAILGATE, FUEL DOORS SYSTEM
AUXILIARY HEATER CTRL
B+ VOLT
BATTERY FUSE BLOCK (ON BATTERY POSITIVE (+) POST
BATTERY STATE OF CHARGE INDICATOR
BLK WIRE
BLK/BRN WIRE
BLK/LT GRN WIRE
BRN/LT BLU WIRE
BRN/LT GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHARGE PORT DOOR POSITION SWITCH (BEHIND REAR OF LEFT FRONT FENDER)
COMPUTER DATA LINES SYSTEM
COOLANT MOTOR ENABLE COMMUNICATION ENABLE COOLING FAN ENABLE
COOLING FAN CTRL SOL VALVE CTRL COOLANT MTR CTRL COOLANT MTR CTRL
COOLING FANS SYSTEM
COOLING FANS SYSTEM AIR CONDITIONING SYSTEM
FAN CONTROL SIGNAL
FUEL DOOR LCK/UNLCK REF COOLANT MOTOR ENABLE
FUEL DOOR LCK/UNLCK SIG
FUSE 6
GMLAN SERIAL DATA
GRY/LT GRN WIRE
HOT AT ALL TIMES
HYBRID/EV BATTERY PACK COOLANT PUMP (FRONT OF ENGINE COMPT, BEHIND RADIATOR)
HYBRID/EV POWERTRAIN CONTROL MODULE 2 (UNDER FRONT PASSENGER'S SEAT)
IGN 1 VOLT
IND CTRL
LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/BRN WIRE
LT BLU/GRY WIRE
LT BLU/VIO WIRE
LT BLU/WHT WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/VIO WIRE
MODE MTR LOW CTRL
MOTOR FEEDBACK SIG PROXIMITY STATUS SIGNAL 1
MTR CTRL
MTR ENABLE
MTR FEED- BACK SIG
MTR FEEDBACK SIGNAL
NCA WIRE
PORT DOOR SENS SIG
PORT DOOR WAKEUP SIG
RED/VIO WIRE
RED/YEL WIRE
TO HYBRID/EV BATTERY PACK (DIAGRAM 6 OF 13)
TO HYBRID/EV BATTERY PACK (DIAGRAM 8 OF 13)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/GRY WIRE
VIO/LT BLU WIRE
VIO/YEL WIRE
WAKEUP SERIAL DATA PORT DOOR RLY CTRL SERIAL DATA 2
WHT WIRE
WHT/BRN WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/YEL WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 1.4l vin 4, hybrid system circuit (4 of 13) -> MTR ENABLE
