Chevrolet Volt I (2010-2015) hybrid/ev powertrain control module 2 (under front passenger's Wiring diagram

5 VOLT REF 63 31 60 33 32 5 VOLT REF LOW PRESS SENS SIG LOW REF LOW REF HI TEMP SENS SIG 72 52 9 HTR SOL VALVE CTRL COOLING FAN CTRL SIG HTR SOL VALVE CTRL A/C LOW SIDE PRESSURE SENSOR (LEFT SIDE OF ENGINE, ON A/C LINE) A/C REFRIGERANT LOW SIDE TEMPERATURE SENSOR (LEFT FRONT OF ENGINE, ON A/C LINE) A/C REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT) ACCESS WAKUP SERIAL DATA 2 B+ VOLT BLK WIRE BLK/BRN WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/VIO WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM COOLANT VALVE POSITION SENS SIG DATA (+) (1) HI SPD GMLAN ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF CYLINDER HEAD) FUSE FUSE HI SPD GMLAN DATA (-) (1) HI VOLT BATT (+) HYBRID/EV POWERTRAIN CONTROL MODULE 1 HYBRID/EV POWERTRAIN CONTROL MODULE 2 (UNDER FRONT PASSENGER'S LOGIC LOW REF LOW SPD SERIAL DATA LT BLU WIRE LT BLU/RED WIRE LT BLU/VIO WIRE LT GRN WIRE NCA WIRE ORG/ WIRE RED/WHT WIRE RUN/CRANK IGNITION 1 VOLT SEAT) VIO/BRN WIRE VIO/DK BLU WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/RED WIRE YEL/LT BLU WIRE
