Chevrolet Volt I (2010-2015) hybrid/ev battery temperature sensor 8 Wiring diagram
This page shows the only wiring diagram for the component.hybrid/ev battery temperature sensor 8, which is found in the car Chevrolet Volt I (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hybrid/ev battery temperature sensor 8 (1 of 1)
10 1 (NOT USED)
10 9 8 7 6 5 4 3 BATT VOL SIG 11 BATT VOL SIG 12
12 11 BATT VOL SIG 9 BATT VOL SIG 10
14 13 BATT VOL SIG 7 BATT VOL SIG 8
16 15 BATT VOL SIG 5 BATT VOL SIG 6
18 17 BATT VOL SIG 3 BATT VOL SIG 4
2 1 LOW REF TEMP SIG 7
2 1 LOW REF TEMP SIG 8
21 20 19 LOW REF BATT VOL SIG 1 BATT VOL SIG 2
BLK/BRN WIRE
BLK/LT BLU WIRE
BLK/VIO WIRE
BRN WIRE
BRN/WHT WIRE
FROM HYBRID/EV BATTERY PACK CURRENT SENSOR (DIAGRAM 7 OF 13)
GRY/YEL WIRE
HYBRID BATTERY PACK SECTION 1
HYBRID/EV BATTERY INTERFACE CONTROL MODULE 1
HYBRID/EV BATTERY MODULE 7
HYBRID/EV BATTERY MODULE 8
HYBRID/EV BATTERY TEMPERATURE SENSOR 7
HYBRID/EV BATTERY TEMPERATURE SENSOR 8
LT BLU WIRE
LT BLU/GRY WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/GRY WIRE
NCA WIRE
TO HYBRD/EV BATTERY MODULE 9 (DIAGRAM 13 OF 13)
VIO WIRE
WHT WIRE
YEL/BRN WIRE
YEL/LT GRN WIRE
Go to component -> Wiring diagram engine performance 1.4l vin 4, hybrid system circuit (12 of 13) -> HYBRID/EV BATTERY TEMPERATURE SENSOR 8
