Chevrolet Volt I (2010-2015) hybrid/ev battery pack coolant temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.hybrid/ev battery pack coolant temperature sensor, which is found in the car Chevrolet Volt I (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hybrid/ev battery pack coolant temperature sensor (1 of 1)
16 17 18 19 20 21 COMMUNICATION ENABLE
6432 6433 COMPUTER DATA LINES SYSTEM
ABS/RESS/ CHRGR FUSE
BATTERY ENERGY CONTROL MODULE
BLK WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FROM HYBRID/EV POWERTRAIN CONTROL MODULE 2
FUSE FUSE (BEHIND REAR OF LEFT FRONT FENDER)
GROUND B+
GRY WIRE
GRY/LT GRN WIRE
HIGH VOLTAGE FAULT SIG
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
HYBRID/EV BATTERY CHARGER RECEPTACLE
HYBRID/EV BATTERY PACK COOLANT HEATER
HYBRID/EV BATTERY PACK COOLANT TEMPERATURE SENSOR
HYBRID/EV BATTERY PACK COOLANT TEMPERATURE SENSOR 2
LOGIC HYBRID/EV BATTERY CONTACTOR ASSEMBLY
LT BLU WIRE
LT BLU/BRN WIRE
LT BLU/GRY WIRE
LT BLU/LT GRN WIRE
LT BLU/WHT WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/LT BLU WIRE
NCA WIRE
ORG/ WIRE
ORG/YEL WIRE
PNK WIRE
RED WIRE
RED/VIO WIRE
RESS FUSE
STORAGE +
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/LT GRN WIRE
Go to component -> Wiring diagram engine performance 1.4l vin 4, hybrid system circuit (6 of 13) -> HYBRID/EV BATTERY PACK COOLANT TEMPERATURE SENSOR
