Chevrolet Volt I (2010-2015) 11 17 dim sw hi beam sig flash to pass sig sw Wiring diagram
This page shows the only wiring diagram for the component.11 17 dim sw hi beam sig flash to pass sig sw, which is found in the car Chevrolet Volt I (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 11 17 dim sw hi beam sig flash to pass sig sw (1 of 1)
1 2 RH HDLP SPLY VOLT LH HDLP SPLY VOLT
11 17 DIM SW HI BEAM SIG FLASH TO PASS SIG SW
18 5 HI BEAM RLY CTRL LF DRL SPLY VOLT
AIR BAG FUSE
AMBIENT LIGHT/ SUNLOAD SENSOR (FRONT CENTER OF DASH)
AMBIENT LT SENS SIG
BATTERY FUSE BLOCK (ON BATTERY POSITIVE (+) POST
BLK WIRE
BLK/BRN WIRE
BODY CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
FUSE 5
GROUND DISTRIBUTION SYSTEM LEFT HIGH BEAM SOLENOID ACTUATOR
GROUND DISTRIBUTION SYSTEM RIGHT DAYTIME RUNNING LAMP
GRY WIRE
GRY/LT BLU WIRE
HEAD PARK AUTO OFF
HEAD- LAMP
HI BEAM DIMMER
HI BEAM FLASH TO PASS SWITCH
HI HI BEAM BEAM LT RT FUSE FUSE
HIGH BEAM RELAY
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
HVAC CONTROL MODULE (CENTER OF DASH)
IGN
INSTRUMENT CLUSTER
LEFT DAYTIME RUNNING LAMP,
LEFT HEADLAMP
LEFT LOW BEAM HEAD- LAMP
LO SPD GMLAN SERIAL DATA
LOGIC
LOW REF
LT BLU BRN/ WIRE
LT BLU WIRE
LT BLU/BRN WIRE
LT GRN WIRE
LT GRN/BRN WIRE
LT GRN/GRY WIRE
OF DASH)
RED WIRE
RED/YEL WIRE
RF DRL SPLY VOLT
RIGHT HEADLAMP
RIGHT HIGH BEAM SOLENOID ACTUATOR
RIGHT LOW BEAM HEAD- LAMP
SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/LT GRN WIRE
WHT WIRE
WHT/LT BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
