Front wiper/washer circuit for Chevrolet Venture I (1996-2005)
Front wiper/washer circuit
BLK WIRE
DK GRN WIRE
FRT/WPR/WSHR FUSE
GROUND
GRY WIRE
HI LO
HI MIST
HI MIST LO OFF DELAY 2 7 0 1 5 0 8 2 3 9
HOT IN ACCY OR RUN
I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING)
LO OFF DELAY
MIST
OFF 6 8 0
PPL
RED WIRE
WASHER SWITCH
WINDSHIELD WASHER PUMP (IN FRONT WASHER SOLVENT CONTAINER)
WINDSHIELD WIPER SWITCH SIGNAL 1 WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/WASHER SWITCH
WIPER SWITCH
YEL WIRE
