Chevrolet Venture I (1996-2005) Charging circuit

ALT/SENSE FUSE BATTERY BATTERY INDICATOR BLK WIRE CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA LINE DK GRN WIRE FUSIBLE LINK A (10 GA- RUST) GENERATOR B+ GENERATOR TERMINAL L OUTPUT GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING) IGN 1 FUSE INSTRUMENT PANEL CLUSTER LOGIC IGN 1 VOLTAGE ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE SPLICE PACK COMPUTER DATA LINES (BELOW STEERING COLUMN, BOTTOM OF KNEE BOLSTER) STARTER UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, FRONT OF RIGHT WHEELHOUSE ABOVE BATTERY)
