Electronic suspension circuit, with inflator for Chevrolet Venture I (1996-2005)
Electronic suspension circuit, with inflator
AIR COMPRESSOR EXHAUST SOLENOID
AIR COMPRESSOR MOTOR
AIR INFLATOR SWITCH
ALC AIR INFLATOR SOL CTRL
ALC EXHAUST SOL CTRL
ALC RLY CTRL COIL SUPP VOLT
AUTO LEVEL CONTROL (ALC) SENSOR (MOUNTED TO REAR CROSSMENBER, ABOVE REAR AXLE)
AUTO LEVEL CONTROL AIR COMPRESSOR RELAY
BATT +
BLK WIRE
ELC/TRAILER FUSE
GROUND
HOT AT ALL TIMES
HOT W/ RAP RELAY ENERGIZED
I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING)
LT BLU WIRE
ORG/ WIRE
PWR QTR VENT FUSE
RIDE CTRL SERIAL DATA ACCES- SORY VOLT
TIMER RLY COIL CTRL
WHT WIRE
YEL WIRE
