Pass-key circuit for Chevrolet Venture I (1996-2005)
Pass-key circuit
B+ GND
BLK WIRE
DATA LINK CONNECTOR (BELOW STEERING COLUMN, BOTTOM OF KNEE BOLSTER)
DK GRN WIRE
FUEL ENABLE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
IGNITION KEY
INSTRUMENT PANEL CLUSTER
ORG/ WIRE
PASS-KEY FUSE
PCM/PASS KEY CLUSTER FUSE
PNK IGN WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (IN AIR CLEANER ASSEMBLY)
PPL
READER/ EXCITER
SECURITY INDICATOR (CLASS 2 MESSAGE)
SERIAL DATA
SPLICE PACK
THEFT DETERRENT CONTROL MODULE
TRANSPONDER
