Manual a/c circuit, with video entertainment for Chevrolet Venture I (1996-2005)

22 26 27 34 39 A/C REQUEST ECT SENSOR A/C PRESS SIGNAL 5 6 13 80 COOLANT FAN 2 COOLANT FAN 1 LOW REF LOW REFERENCE A/C CLU DIODE A/C CLU FUSE A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C REFRIGERENT PRESSURE SENSOR (LEFT SIDE OF ENGINE COMPT, BELOW ACCUMULATOR) BLK WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLOWER MOTOR RESISTOR ASSEMBLY BRN WIRE COMP CONTROL COOL FAN 1 FUSE COOL FAN 1 RELAY COOL FAN 2 RELAY COOL FAN RELAY DEFOGGER SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRL/HVAC/ TEMP/HTD ST FUSE ENGINE CONTROLS SYSTEM EVAPORATIVE TEMPERATURE SENSOR (BEHIND CENTER OF DASH, ON HVAC ASSEMBLY) FRT HVAC HI BLWR C.B. GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HVAC BLOWER FUSE HVAC CONTROL MODULE I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) LAMP DIM SIG BLOWER SW OFF RIGHT TEMP ACT AUX MODE DOOR CTRL LEFT TEMP ACT LEFT AIR TEMPERATURE ACTUATOR (LEFT SIDE OF HVAC MODULE) LEFT COOLING FAN (MOUNTED TO RADIATOR) LT BLU WIRE MODE ACTUATOR (LEFT SIDE OF HVAC MODULE) NCA WIRE OFF LO ORG/ WIRE ORG/BLK WIRE PPL PPL 72 63 60 RADIO FUSE COOL FAN 2 FUSE RED WIRE RED/BLK WIRE RIGHT AIR TEMPERATURE ACTUATOR (RIGHT SIDE OF HVAC MODULE) RIGHT COOLING FAN (MOUNTED TO RADIATOR) RUN WIRE TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE

AUXILIARY AIR TEMPERATURE ACTUATOR (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR RELAY (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR RESISTOR (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR SWITCH (PART OF MULTI- FUNCTION SWITCH) AUXILIARY MODE ACTUATOR (BEHIND LEFT REAR WHEELWELL) BLK WIRE BRN WIRE GRY WIRE HOT IN RUN I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) LT BLU WIRE ORG/ WIRE REAR VIDEO/ AUDIO/HVAC MODULE RED WIRE RR HVAC/ TEMP CONT FUSE TEMP CONTROL WHT WIRE YEL WIRE
