Chevrolet Venture I (1996-2005) window switch- front passenger Wiring diagram
This page shows the only wiring diagram for the component.window switch- front passenger, which is found in the car Chevrolet Venture I (1996-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram window switch- front passenger (1 of 1)
AJAR INDICATOR SWITCH
AUTO LEVEL CONTROL (ALC) AIR COMPRESSOR
AUTO LEVEL CONTROL (ALC) SENSOR
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL) REAR WINDOW DEFOGGER GRID
DOOR LOCK CYLINDER SWITCH- LIFTGATE
DOOR LOCK CYLINDER SWITCH-LF
DOOR LOCK CYLINDER SWITCH-RF
DOOR LOCK SWITCH PLATE-LEFT (DOOR MOUNTED)
DOOR LOCK SWITCH PLATE-LEFT (PILLAR MOUNTED)
DOOR LOCK SWITCH PLATE-RIGHT (DOOR MOUNTED)
DOOR LOCK SWITCH PLATE-RIGHT (PILLAR MOUNTED)
DOOR LOCK SWITCH- DRIVER
DOOR LOCK SWITCH- FRONT PASSENGER
DRIVER DOOR LOCK ACTUATOR
FRONT PASSENGER DOOR LOCK ACTUATOR
LICENSE LAMPS
LIFTGATE DOOR LOCK
MIRROR DEFOGGER
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
OUTSIDE REARVIEW MIRROR- DRIVER
OUTSIDE REARVIEW MIRROR- PASSENGER
POWER SLIDING DOOR OPEN/CLOSE SWITCH
SLIDING DOOR DETENT SWITCH- LEFT
SLIDING DOOR DETENT SWITCH- RIGHT
SLIDING DOOR JAMB SWITCH- LEFT
SLIDING DOOR JAMB SWITCH- RIGHT
SLIDING DOOR UNLATCH ACTUATOR- LEFT
SLIDING DOOR UNLATCH ACTUATOR- RIGHT
TRAILER WIRING HARNESS
WINDOW SWITCH- DRIVER
WINDOW SWITCH- FRONT PASSENGER
WINDOW WIPER MOTOR- REAR
Go to component -> Ground distribution circuit (3 of 3) -> WINDOW SWITCH- FRONT PASSENGER
