Chevrolet Venture I (1996-2005) stop lamp sw out serial data sig desired torque Wiring diagram
This page shows the only wiring diagram for the component.stop lamp sw out serial data sig desired torque, which is found in the car Chevrolet Venture I (1996-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp sw out serial data sig desired torque (1 of 1)
102 302 251 2050 BATTERY BATTERY GROUND GROUND
ANTI-LOCK BRAKE IND
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH (ON RIGHT SIDE OF BRAKE FLUID RESERVOIR)
BRAKE IND
BRAKE PRESSURE MODULATOR VALVE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR (DLC) (BELOW STEERING COLUMN, ON KNEE BOLSTER)
DELIVERED TORQUE
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (AT LOWER LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK Y
FUSIBLE LINK Z
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
INSTRUMENT PANEL CLUSTER
IP FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT OPENING)
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LT BLU WIRE
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PCM/ABS FUSE
PNK WIRE
PPL
PUMP MOTOR
REAR FOG LAMP/ TCS SWITCH
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
SERVICE TRACTION SYSTEM
SPLICE PACK
STOP LAMP SW OUT SERIAL DATA SIG DESIRED TORQUE
STOPLAMP FUSE
STOPLAMP SWITCH (ON TOP OF BRAKE PEDAL SUPPORT)
TAN WIRE
TAN/BLK WIRE
TRAC OFF IND
TRACTION ACTIVE
TRACTION CTRL ON/OFF SIG
UNDERHOOD JUNCTION BLOCK
VENT TUBE
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit -> STOP LAMP SW OUT SERIAL DATA SIG DESIRED TORQUE
