Chevrolet Venture I (1996-2005) rear window wiper/ washer and multi- function switch Wiring diagram
This page shows the only wiring diagram for the component.rear window wiper/ washer and multi- function switch, which is found in the car Chevrolet Venture I (1996-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window wiper/ washer and multi- function switch (1 of 1)
BLK WIRE
DELAY
DK GRN WIRE
DN (+)
GRY WIRE
HOT IN ACCY OR RUN
I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING)
ILLUM
PARK
PULSE
REAR WINDOW WASHER FLUID PUMP (IN REAR WASHER SOLVENT CONTAINER)
REAR WINDOW WIPER MOTOR (ON CENTER OF LIFTGATE)
REAR WINDOW WIPER/ WASHER AND MULTI- FUNCTION SWITCH
REAR WINDOW WIPER/ WASHER SWITCH
RR WPR/WSHR FUSE
RUN WIRE
UP (+)
WASH
WHT WIRE
WIPER MOTOR
