Chevrolet Venture I (1996-2005) pressure control sol valve tcc pwm sol 2-3 shift sol Wiring diagram

1-2 SHIFT SOL AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION FLUID TEMPERATURE SENSOR AUTOMATIC TRANSMISSION INPUT SHAFT SPEED SENSOR BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (DLC) (PARTIAL) (BELOW STEERING COLUMN, ON KNEE BOLSTER) PPL DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ECM SENSE FUSE ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON TOP LEFT REAR OF ENGINE) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING) IGN IGN 1 FUSE IGN 1 IGN 0 INSTRUMENT PANEL CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (ON TOP RIGHT SIDE OF ENGINE) ORG/ WIRE ORG/BLK WIRE PCM/ PASSKEY CLUSTER FUSE PNK PNK WIRE PNK WIRE PPL PRESSURE CONTROL SOL VALVE TCC PWM SOL 2-3 SHIFT SOL RED WIRE RED/BLK WIRE SERVICE ENGINE SOON IND STOPLAMP SWITCH (MOUNTED ON TOP OF BRAKE PEDAL SUPPORT) STOPLIGHT SWITCH, BODY CONTROL MODULE (BCM), REAR DOOR ACTUATOR CONTROL MODULES TAN WIRE TCC FUSE TCC/ BRAKE SWITCH THEFT DETERRENT CONTROL MODULE THROTTLE POSITION (TP) SENSOR (ON TOP OF ENGINE, ON THROTTLE ASSEMBLY) TRANSMISSION INTERNAL MODE SWITCH (IMS) UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, FRONT OF RIGHT WHEELHOUSE ABOVE BATTERY) VEHICLE SPEED SENSOR (VSS) (MOUNTED TO RIGHT SIDE OF TRANSAXLE) WHT WIRE YEL WIRE YEL/BLK WIRE
