Chevrolet Venture I (1996-2005) low speed cool fan relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.low speed cool fan relay ctrl, which is found in the car Chevrolet Venture I (1996-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low speed cool fan relay ctrl (1 of 1)
BLK WIRE
BLU WIRE
COOL FAN 1 FUSE
COOL FAN 1 RELAY
COOL FAN 2 FUSE
COOL FAN 2 RELAY
COOL FAN RELAY
DK BLU WIRE
DK GRN WIRE
ECT SENSOR
ENGINE CONTROLS SYSTEM (MAP SENSOR)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (TOP LEFT REAR OF ENGINE)
GRN WIRE
GRY WIRE
HIGH SPEED COOL FAN RELAY CTRL
HOT AT ALL TIMES
LEFT COOLING FAN (MOUNTED TO RADIATOR)
LOW REF
LOW SPEED COOL FAN RELAY CTRL
LT BLU WIRE
ORG/ WIRE
ORG/BLK WIRE
RIGHT COOLING FAN (MOUNTED TO RADIATOR)
UNDERHOOD FUSE BLOCK (ON RIGHT FRONT OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> LOW SPEED COOL FAN RELAY CTRL
