Chevrolet Venture I (1996-2005) left side mirror turn indicator light Wiring diagram
This page shows the only wiring diagram for the component.left side mirror turn indicator light, which is found in the car Chevrolet Venture I (1996-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side mirror turn indicator light (1 of 1)
BLK WIRE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DK BLU WIRE
DK GRN WIRE
ELC FUSE
HOT AT ALL TIMES
I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING)
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT REAR TAIL LAMP
LEFT REAR TAIL/STOP LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT SIDE MIRROR TURN INDICATOR LIGHT
LEFT TAILLAMP
LICENSE LAMPS
LT BLU WIRE
NCA WIRE
ORG/ WIRE
RED WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT REAR TAIL LAMP
RIGHT REAR TAIL/STOP LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT SIDE MIRROR TURN INDICATOR LIGHT
RIGHT TAILLAMP
STOP LAMP FUSE
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT)
TRAILER WIRING HARNESS (CUT AS BLUNT ENDS)
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LEFT SIDE MIRROR TURN INDICATOR LIGHT
