Chevrolet Venture I (1996-2005) amber center ind ctrl amber outside ind ctrl Wiring diagram

AMBER CENTER IND CTRL AMBER OUTSIDE IND CTRL AMBER CENTER INDICATOR AMBER OUTSIDE INDICATOR B/U LAMP FUSE BLK WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) DK BLU WIRE DK GRN WIRE ENGINE CONTROLS SYSTEM GROUND B+ SW SIG IN BACKUP LAMP VOLTAGE DIAGNOSTIC INPUT PNK WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK IGN 1 FUSE INDICATOR INSTRUMENT PANEL CLUSTER INTERIOR LAMP AND MULTI-FUNCTION SWITCH ASSEMBLY LEFT REAR CORNER OBJECT SENSOR (IN LEFT CORNER OF REAR BUMPER) LEFT REAR MIDDLE OBJECT SENSOR (IN LEFT MIDDLE OF REAR BUMPER) LOW REF LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH PNK WIRE REAR PARK CHIME SIG TELLTAIL ASSY VOLTAGE REAR PARKING AID OVERRIDE SWITCH REAR PARKING ASSIST DIAGNOSTIC CONNECTOR REAR PARKING ASSIST DISPLAY RED IND CTRL WIRE RED WIRE RIGHT REAR CORNER OBJECT SENSOR (IN RIGHT CORNER OF REAR BUMPER) RIGHT REAR MIDDLE OBJECT SENSOR (IN RIGHT MIDDLE OF REAR BUMPER) SENSOR SIGNAL SUPPLY VOLTAGE UNDERHOOD FUSE BLOCK VSS SIGNAL WHT WIRE YEL WIRE
