Chevrolet Venture I (1996-2005) ajar indicator switch Wiring diagrams

8 15 GROUND BATTERY AJAR INDICATOR SWITCH BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) BRN/WHT WIRE CTSY/ LAMP FUSE DK BLU WIRE DOOR LOCKS SYSTEM (DOOR LOCK SWITCHES) DRIVER DOOR LOCK CYLINDER SWITCH GRN WIRE GROUND BATTERY BATTERY HORNS SYSTEM HEADLIGHTS SYSTEM HOT AT ALL TIMES I/P FUSE BLOCK IGNITION KEY ALARM SWITCH LEFT FRONT DOOR LOCK LEFT SLIDING DOOR JAMB SWITCH LIFTGATE LOCK LIFTGATE LOCK CYLINDER SWITCH LOCK OUT LO LT BLU WIRE LT GRN WIRE NCA WIRE ONSTAR FUSE ORG/ WIRE ORG/BLK WIRE PWR LOCK FUSE RADIO FUSE RED WIRE RED/BLK WIRE REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND CENTER OF DASH) RIGHT FRONT DOOR LOCK RIGHT FRONT DOOR LOCK CYLINDER SWITCH RIGHT SLIDING DOOR JAMB SWITCH TAN WIRE THEFT LED UN- LOCK LOCK UNDERHOOD FUSE BLOCK VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BELOW LEFT SIDE OF DASH) WHT WIRE YEL WIRE

AJAR INDICATOR SWITCH AUTO LEVEL CONTROL (ALC) AIR COMPRESSOR AUTO LEVEL CONTROL (ALC) SENSOR BLK WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) REAR WINDOW DEFOGGER GRID DOOR LOCK CYLINDER SWITCH- LIFTGATE DOOR LOCK CYLINDER SWITCH-LF DOOR LOCK CYLINDER SWITCH-RF DOOR LOCK SWITCH PLATE-LEFT (DOOR MOUNTED) DOOR LOCK SWITCH PLATE-LEFT (PILLAR MOUNTED) DOOR LOCK SWITCH PLATE-RIGHT (DOOR MOUNTED) DOOR LOCK SWITCH PLATE-RIGHT (PILLAR MOUNTED) DOOR LOCK SWITCH- DRIVER DOOR LOCK SWITCH- FRONT PASSENGER DRIVER DOOR LOCK ACTUATOR FRONT PASSENGER DOOR LOCK ACTUATOR LICENSE LAMPS LIFTGATE DOOR LOCK MIRROR DEFOGGER NCA WIRE OUTSIDE REARVIEW MIRROR SWITCH OUTSIDE REARVIEW MIRROR- DRIVER OUTSIDE REARVIEW MIRROR- PASSENGER POWER SLIDING DOOR OPEN/CLOSE SWITCH SLIDING DOOR DETENT SWITCH- LEFT SLIDING DOOR DETENT SWITCH- RIGHT SLIDING DOOR JAMB SWITCH- LEFT SLIDING DOOR JAMB SWITCH- RIGHT SLIDING DOOR UNLATCH ACTUATOR- LEFT SLIDING DOOR UNLATCH ACTUATOR- RIGHT TRAILER WIRING HARNESS WINDOW SWITCH- DRIVER WINDOW SWITCH- FRONT PASSENGER WINDOW WIPER MOTOR- REAR
