Rear quarter windows circuit for Chevrolet Uplander I (2004-2008)
Rear quarter windows circuit
BLK WIRE
BRN WIRE
CLOSE
ELC FUSE 2
HOT W/ RAP RELAY 29 ENERGIZED
I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
LEFT REAR QUARTER WINDOW ACTUATOR (BEHIND LEFT REAR INTERIOR BODY PANEL)
OVERHEAD CONSOLE MULTIFUNCTION SWITCH
RIGHT REAR QUARTER WINDOW ACTUATOR (BEHIND RIGHT REAR INTERIOR BODY PANEL)
TAN WIRE
YEL WIRE
