Car Wiring Diagrams for Defoggers circuit for Chevrolet Uplander I (2004-2008)

BLK WIRE BODY CONTROL MODULE (BCM) CLASS 2 DATA CLASS 2 SERIAL DATA DEF INDICATOR CONTROL DEFOGGER REQUEST DEFOGGER SWITCH DK GRN WIRE DRIVER OUTSIDE REARVIEW MIRROR HOT AT ALL TIMES HTD/ MIR FUSE 16 HVAC CONTROL MODULE (IN DASH CENTER TRIM PANEL, BENEATH RADIO) I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) IGN IGN DEFOGGER INDICATOR LT GRN WIRE MIRROR DEFOGGER NCA WIRE ORG/ WIRE PASSENGER OUTSIDE REARVIEW MIRROR MIRROR DEFOGGER REAR FOG RELAY CONTROL REAR WINDOW DEFOGGER GRID RED WIRE RR DEFOG FUSE 36 RR DEFOG RELAY 30 SPLICE PACK UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL) WHT WIRE
